プリンテッドエレクトロニクスの製造 2023-2033年


Manufacturing Printed Electronics 2023-2033

「プリンテッドエレクトロニクスの製造 2023-2033年」は、プリンテッドエレクトロニクス機器市場における発展、変遷、技術革新について調査している。40社以上の企業とのインタビューや交流から、... もっと見る





出版社 出版年月 電子版価格 ページ数 言語
IDTechEx
アイディーテックエックス
2022年12月21日 US$6,500
電子ファイル(1-5ユーザライセンス)
ライセンス・価格情報・注文方法はこちら
263 英語

日本語のページは自動翻訳を利用し作成しています。




サマリー

「プリンテッドエレクトロニクスの製造 2023-2033年」は、プリンテッドエレクトロニクス機器市場における発展、変遷、技術革新について調査している。40社以上の企業とのインタビューや交流から、3種類のアナログ印刷と5種類のデジタル印刷の属性、準備レベル、ユースケース、市場需要を評価しています(これらの競合技術のスループット、最小フィーチャーサイズ、適合インク粘度は明確に示されています)。また、真空蒸着、アディティブサーキットプロトタイピング(2Dおよび3Dの両方)、フレキシブルハイブリッドエレクトロニクス製造の重要なステップである実装部品についても取り上げています。さらに、ロール・ツー・ロールのR2Rエレクトロニクス製造への移行に関連する動機、課題、促進技術についても包括的にカバーしている。

本レポートは、IDTechExのプリント/フレキシブルエレクトロニクス市場における現行および新興アプリケーションの包括的なカバレッジに基づき、各製造方法をアプリケーションごとにさらにセグメント化し、50以上の明確な予測ラインを提供しています。既存企業から革新的な新興企業まで、各企業とのインタビューや交流から得られた主要な知見は、SWOT分析とともに技術とビジネスモデルの両方についての議論を含む40以上の詳細な企業プロファイルを通じて提供されています。全体として、本レポートはプリンテッド/フレキシブルエレクトロニクスのトレンドと競合技術について包括的な見解を示しています。


R2R製造への移行
プリンテッド/フレキシブルエレクトロニクスの主要な価値提案として、高速ロール・ツー・ロール(R2R)製造への適合性がよく挙げられています。リジッド基板から銅をエッチングするのではなく、フレキシブル基板に機能をプリントすることで、従来のグラフィック印刷と同様の製造方法(したがってスループット)を実現することができます。このような高いスループットにより、製造装置の固定費をより多くの回路で共有できるため、製造コストの総額は、使用する材料によって決まることになります。R2Rエレクトロニクスは、ユビキタスエレクトロニクスを促進し、スマートパッケージや電子皮膚パッチなどの技術をコスト効率よく生産するために重要な役割を果たすと考えられています。さらに、R2Rエレクトロニクスの高いスループットは、太陽光発電パネルや照明などの大面積デバイスの製造に理想的である。

しかし、これまでのところ、RFIDを除くほとんどのR2Rエレクトロニクス製造は、研究センターやパイロットラインに留まっています。R2Rエレクトロニクス製造の導入には、十分な受注量の確保、品質管理、部品の取り付けなどの課題があります。本レポートでは、これらの課題を明らかにし、高スループットのデジタル印刷、非接触インライン導電率測定、フォトニックソルダリングなどの新しい技術的ソリューションについて概説しています。

印刷方式
スクリーン印刷は、高粘度のフレーク状導電性インクとの相性が良く、1回の印刷で厚みのあるトレースを形成できるため、現在、プリンテッドエレクトロニクス製造の主流となっている。また、ファインダーメッシュの開発により、スクリーン印刷で実現できる解像度(=最小フィーチャーサイズ)は着実に向上している。しかし、スクリーン印刷は、唯一の成膜方法とは言い難い。

フレキソ印刷など従来のアナロググラフィック印刷の多くはプリンテッド/フレキシブルエレクトロニクスに適用できるが、技術革新の多くは、ラピッドプロトタイピングを可能にし、多品種少量生産(HMLV)を促進するデジタル成膜手法の中にある。特に注目すべきは、インクジェット、スクリーン印刷、レーザーダイレクトストラクチャリングの利点を組み合わせたと考えられるレーザー誘起前方転写(LIFT)である。このデジタル方式は、粘性の高いインクを扱うことができ、光学的に駆動するため高い処理能力を持ち、非接触のため非平面にも使用できる。

また、サブトラクティブ方式で実現されている長さスケールを、アディティブ・デジタル・マニュファクチャリングで実現しようとする新たな印刷方式もある。EHD(電気流体力学)プリンティングは、電界を利用して1ミクロンの軌跡を作るもので、プロトタイピングや修理のために徐々に実用化されつつある。さらに、複数の企業がMEMS(マイクロエレクトロメカニカルシステム)プリントヘッドを使用したマルチノズルシステムを開発し、長年にわたるスループットと粘度のトレードオフを多少解消しつつある。

今後の展望
昨年、自動車用バックライト付き静電容量式タッチセンサーなど、複数の製品が大きな商業的普及を遂げ、プリンテッド/フレキシブルエレクトロニクスにとってエキサイティングな時期となっている。しかし、最も魅力的な成長機会は、プリンテッド/フレキシブル・エレクトロニクスによって促進されるアプリケーションであることは間違いないだろう。健康状態を継続的に監視する電子皮膚パッチやスマート包装はその好例ですが、許容できる価格帯でフレキシブル回路を製造するには、高スループットのR2R製造が必要になります。また、高解像度EHDプリントのスループットが向上すれば、この分野やマイクロ流体工学などの新しいアプリケーションを開拓することができます。

本レポートで回答した主な質問
  • プリンテッド/フレキシブルエレクトロニクスを様々な長さスケールとスループットで製造するための選択肢は?
  • サブトラクティブマニュファクチャリングに対するアディティブマニュファクチャリングの利点は?
  • プリンテッド/フレキシブルエレクトロニクス向けの新たな製造技術にはどのようなものがあるか、またその技術的および商業的な準備状況はどのようになっているか?
  • R2Rエレクトロニクス製造の導入に伴う課題とは何でしょうか?どうすれば解決できるでしょうか?
  • 各アプリケーションに最適な製造技術は?
  • 各製造技術を製造しているキープレイヤーは誰ですか?その比較は?
  • フレキシブルハイブリッドエレクトロニクスを促進する部品配置と取り付けの革新的技術とは?

IDTechExは、印刷と製造方法を含むプリンテッド・エレクトロニクスとフレキシブル・エレクトロニクスをカバーする20年にわたる専門知識を有しています。当社のアナリストは、多くの装置サプライヤーや製品開発者にインタビューを行うとともに、LOPECやFLEXなどの複数のプリンテッドエレクトロニクス会議に毎年出席することで、この技術と関連市場の最新動向を綿密に追ってきました。本レポートは、この新しい技術の製造状況を総合的に把握し、製品開発および大量生産へのスケールアップの際の選択を支援するものです。

主な内容
本レポートでは、以下の情報を提供しています:

技術動向とメーカー分析:
  • アナログとデジタルの7つの印刷方式について、議論、比較、評価を行っています。レーザー誘起前方転写(LIFT)、複数のノズルから同時に印刷する電気流体力学(EHD)、インパルス印刷など、斬新な機能を持つデジタル製造法も含まれています。
  • 製造装置サプライヤー、受託製造業者、製造者について、SWOT分析および規模、価値提案とターゲットアプリケーションの考察を含む40社以上の企業プロファイルを掲載しています。
  • プリンテッドエレクトロニクスの主要な潜在的利益であるR2R製造の現状、課題、機会に関する考察。
  • アナログとデジタルの製造方法について、スループット、最小フィーチャーサイズ、インク粘度によるベンチマークを実施。
  • 様々な製造技術がどのように生産および研究所で展開されているかを概説する多くのケーススタディ。
  • フレキシブル・ハイブリッド・エレクトロニクス(FHE)の実現に不可欠なフォトニックソルダリングや直接転写などの新しい部品実装方法についての議論と評価。また、超低温ハンダや電界配向型導電性接着剤など、新たな部品実装材料についても議論しています。
  • 2Dと3Dの両方で競合するアディティブ回路プロトタイピング技術についてのレビュー。
  • 各製造方法がどのアプリケーションに最も適しているかの評価。

市場予測および分析:
  • 各製造方法の市場規模および10年間の市場予測(生産される回路面積)、アプリケーション別に分類。
  • 競合するアナログとデジタルの製造方法の技術的および商業的な準備状況の評価。
