サマリー

2014年にアップルがLuxVueを買収した後、マイクロ発光ダイオード(MicroLED、μLED)は魅力的な発光ディスプレイ技術となり、さまざまな業界のプレーヤーによって追求されている。μLEDディスプレイは、微細な発光ダイオード(LED)のアレイをベースとしており、従来のディスプレイと比較して、広色域、高輝度、低消費電力、優れた安定性と長寿命、広視野角、高ダイナミックレンジ、高コントラスト、高速リフレッシュレート、透明性、シームレスな接続、センサー統合機能などの明確な利点がある。このような価値提案の一部は、LCD、OLED、QDなどの代替製品によって提供される可能性があるが、μLEDディスプレイを開発する強力な原動力の1つは、このような独自の価値提案である。

各種ディスプレイ技術の価値提案。出典:IDTechEx

最初のμLED商業製品であるCrystal LEDディスプレイはソニーによって発売され、従来のパッケージLEDをμLEDに置き換えた。これらの小さなピッチのLEDビデオ・ディスプレイは、to-B市場をターゲットとしており、コストと価格の両方が、すでに存在するものよりもはるかに高価である。技術の未熟さ、コストの障壁、サプライチェーンの未完成は、マイクロLEDディスプレイの大規模商業化における3つの大きなハードルである。

確立されたLED産業と発達したディスプレイ分野の基礎の上に、新興の物質移動と統合分野が、これら2つの産業を橋渡しする極めて重要な役割を果たしている。両者が一体となることで、新たなサプライチェーンが確立される可能性がある。現在のLCD製造はコスト優位性から中国にシフトしており、OLEDディスプレイは韓国が独占している。このゲームは、従来のLEDサプライヤー、ディスプレイベンダー、先端材料プレーヤー、部品プロバイダー、OEM、インテグレーター、ツール提供者に開かれており、技術革新、材料改良、設備サポート、ビジネスモデル革命をもたらすことができる新規参入者も歓迎する。

戦略的決定を下すには、情報と洞察の両方が必要である。これには、技術の限界と能力、市場の現状分析、サプライチェーンの解釈、プレーヤーの活動追跡、世界的なトレンドの把握などが含まれるが、これらに限定されるものではない。本レポートでは、これらの側面に適宜取り組んでいく。

μLEDディスプレイを製造するには、エピタキシー、フォトリソグラフィ、チップ製造、基板除去、検査、物質移動、接着と相互接続、テスト、修理、バックプレーンとドライブICなど、多くの技術とプロセスが関与している。長年の開発の結果、いくつかの技術的な困難は解決されましたが、一方で新たな挑戦が私たちの前に立ちはだかっています。例えば、数年前、主要な努力はダイの微細化、チップの設計、質量移動などに集中していた。最近では、すべてのプロセスを完全に理解することが重要であると認識するプレーヤーが増えている。そのため、歩留まりや生産性の向上だけでなく、検査、リペア、駆動、画像改善、光管理などの技術にも力を入れる人が増えている。現在、市販のマス・トランスファーおよびボンディング・ツールが市販されている。本レポートでは、主な技術の選択肢をすべて、詳細な紹介、分析、比較で紹介している。また、重要なプレーヤーがどのようなものを市場に提供してきたか、そのプロトタイプ/製品の背景にある技術も示している。対象とするアプリケーションは、AR/VR/MRのようなマイクロディスプレイから、スマートフォンやテレビのような消費者向け中型ディスプレイ、大型映像公共ディスプレイのような巨大ディスプレイまでカバーしている。対応する技術もそれぞれ異なる。各技術を深く理解することで、現在地と今後の方向性を理解することができる。時が経つにつれて、μLEDディスプレイを使った4つのアプリケーションが徐々に際立ち、明確な差別化をもたらしている: AR/MR、ウェアラブル、車載ディスプレイ、大型ビデオディスプレイである。その一方で、柔軟性や透明性など、他の機能もさまざまな技術プロバイダーによって実証されている。


さまざまな技術を持つプレーヤーがいるため、狙うべき参入市場も異なる。本レポートでは、7つのアプリケーションに焦点を当てて分析した。AR/MR(拡張現実/複合現実)、VR(仮想現実)、大型映像ディスプレイ/テレビ、車載ディスプレイ、携帯電話、スマートウォッチとウェアラブル、タブレットとノートPCである。各アプリケーションの出荷台数と市場金額に基づいて、10年間の市場予測を提供する。さらに、アプリケーションごとに異なる成熟度を考慮したアプリケーションロードマップも提供している。

より多くのプレーヤーがµLED産業に参入するにつれて、これらのプレーヤーは次第に互いに直接、または大規模なネットワークで協力することを選択するようになる。サプライチェーンのクラスターは地理的に形成され、大陸を越えた連携がますます一般的になっている。本レポートでは、地域別の取り組みも紹介している。

こうした協力関係はすべて、グローバル化が今後も続くことを示している。また、展示サイクルからは、現在が合併・統合の段階にあることがわかる。

レポートの目的

技術評価
  • 競合技術と比較した価値提案、利点と欠点
  • 推進要因と動機
  • 現状
  • 技術のブレークスルー
  • 技術的課題とその解決に向けたロードマップ
  • 研究機関、大学、新興企業の活動

応用分野
  • ディスプレイ用途のロードマップ
  • これらの用途におけるμLEDの成熟度と破壊力
  • 近い将来に期待されること

市場環境、ビジネスチャンス、サプライチェーン
  • コスト分析
  • サプライチェーンへの影響とμLEDディスプレイの可能なサプライチェーンの特定
  • 市場予測
  • 地域別取り組み
  • 合併、買収、合弁事業、パートナーシップ

プレーヤー
  • 主要プレーヤー、IP所有者、新興新興企業の特定

誰が読むべきか:ディスプレイメーカー、LEDサプライヤー、材料サプライヤー、研究開発機関、技術プロバイダー、OEM/ODM、投資家、新たなビジネスチャンスを探るプレイヤー
