米国調査会社ポーマノックパブリケーションズ社(Paumanok Publications)の調査レポート「ニッケル電極粉末とペースト：世界市場、技術、ビジネスチャンス　2019-2024年」は、積層型セラミックチップコンデンサ(MLCC)の電極レイヤに使用されている超高純度のニッケル電極粉末とペーストの世界市場について詳述している。世界のニッケル電極MLCC粉末の消費金額と数量を査定し、キロ当たりの平均価格も記載している。世界のMLCC用のニッケル電極ペースト市場の粉末からペーストへのサプライチェーンと、最善のペーストが得られる業者市場や多くのペーストがMLCCメーカに独占されている現状について述べている。

Quick Overview

(Durham, NC USA) Paumanok IMR announces the release of the advanced research project report entitled “Nickel Electrode Powder and Paste: World Markets, Technologies and Opportunities: 2019-2024 ISBN: 1-89-3211-38-X (2019)” , which takes a detailed look at the global market for ultra-high purity nickel electrode powders and pastes consumed as the electrode layers of multilayered ceramic chip capacitors (MLCC).

POWDER: This study updates the 1995 and 2005 studies of the same title by the same publisher and the same author. The study analyzes the global value and volume of consumption for nickel electrode MLCC powder, as well as the average price per kilogram over time as benchmarked by the prior studies. The study establishes the long-term historical value, volume and pricing for nickel electrode powder over time. The study also details the value of consumption for nickel electrode powder by particle size, and establishes price and end-product consumption points of differentiation based upon the mean particle size of the powder (<0.1, 0.1-0.19, 0.2-0.3, 0.4 to 0.5+ nm diameter). The study also discusses the world’s top customers for nickel electrode powder by country and world region, including an analyses of all known factories producing MLCC by country (80+ MLCC Factories By Country and Location Worldwide). The study also addresses the detailed “matching systems” for nickel electrode powder and pastes in ceramic dielectrics and termination materials, and synergies between vendors of PBM and BME, barium titanate and additive materials.

PASTE: The study also addresses the global paste nickel electrode paste markets for MLCC, detailing the supply chain from powder to paste and addresses how some of the best pastes are available form the merchant market, but how most paste is produced captive by the MLCC manufacturers. Most importantly the study addresses recent changes in the market, including the captive development of nickel electrode powder and paste by some of the world’s top MLCC producers. Market share data for (1) nickel powders and (2) nickel pastes are also given by vender.

MLCC ROADMAP FORWARD: The study also shows the roadmap of development with respect to the application of nickel electrode powder in MLCC going forward and the recent breakthroughs in nanotechnology and paste development that have enabled (A) a dramatic increase in capacitance value in microfarads per MLCC, as well as a (B) potential to increase voltage per MLCC to threaten alternative electrolytic capacitor technologies. FORECASTS: The outlook for nickel electrode powder consumed in MLCC is discussed in terms of its ability to win new designs in emerging markets as it competes against related electrostatic and electrolytic material systems. The study also addresses recent spikes in MLCC market activity, MLCC shortages and "EOL" timeliness, and the resulting capacity expansion by the major MLCC manufacturers in 2019 as well as long term market forecasts to 2024. See the detailed Table of Contents for greater insight into the scope and depth of this advanced project Paumanok IMR research report. Updates the 1995 and 2005 study of the same title.

Nickel Electrode Powder and Paste: World Markets, Technologies and Opportunities: 2019-2024 ISBN: 1-89-3211-38-X (2019); 180 Pages, 80 Figures; Published September 2019. $3,750.00 Single User License.
